2003 Bianchi Campione

TYPE:
20 speed - road / race type - 2003 model Campione (...in name only, as it has been modified way beyond recognition as such)

SIZE:
61 cm : 610 mm (virtual seat tube) / 580 mm (physical seat tube C-t-T) - 586 mm (virtual top tube) / 574 mm (physical top tube C-t-C) - 415 mm (chainstay) - 100.5 mm (wheelbase) - 32.5 inches (standover height) - 40 degree (fork rake) - 73 degree (head tube angle) - 72.5 degree (seat tube angle)

COLOR:
Laser Blue head tube and rear stay ends / dropouts with color fade into Mystery Blue main frameset - Laser Blue graphics - protective clear coat

FRAME:
Bianchi Mega-Pro design - made in Italy - Reparto Corse compact frame with sloping top tube - RC Cromo Lite double-butted CrMo alloy steel - TIG welded - dual bottle mounts - vertical dropouts

FORK:
Reynolds Ouzo Pro Aero - carbon fiber fork with 1" carbon fiber threadless steer tube - unicrown design - 40 degree rake - 700c - 2004 model Ouzo Pro Aero

HEADSET:
Chris King - alloy 1" threadless headset - 31.4 mm stack height - Black - 2004 model "No ThreadSet" : Le Tour carbon fiber headset spacers - 5 mm each (5 mm over / 25 mm under)

STEM:
ITM Millennium Adjustable - CNC Ergal 7075-T6 alloy - 100 mm - 25.8 mm clamp - two bolt quick release - 2004 model Millennium Adjustable : SRP titanium stem & handlebar clamp bolts - M5 .8 x 20 mm SHCS - model SH5-20

HANDLEBARS:
ITM Millennium - Black anodized Ergal 7075-T6 alloy - anatomic profile - 46 cm O-t-O / 25.8 mm clamp / 91 mm reach / 154 mm drop - 2004 model : Delta - Aztec Vibe Wrap System - ergonomic handlebar dampening system - closed cell foam - model CW100B : Profile Design Split Second aerobars - 60601-T6 alloy - flip up ZB brackets - 17° angle F-19 armrests - model PD-SSZ / Cee Gee's aero pads - Black - model F-19 : Bianchi - logo embossed cork handlebar tape - Black - model H1014

BOTTOM BRACKET:
Phil Wood - alloy cartridge - adjustable type BB for 68 mm shell - 17 mm titanium spindle - square taper - 102 mm symmetrical without offset - model BRP02 : 1.370 x 24 TPI English thread BB cartridge cups - Clear anodized aluminum alloy - model BMRBA

CRANKSET:
Campagnolo Chorus CT Compact - 110 mm BCD - 34/50 Ultra-Drive aluminum alloy chain rings with EPS finish - integrated fifth spider - 175 mm carbon fiber arms - 9/16" x 20 TPI pedal thread - 10s - 2005 model FC5-CH...C : SRP M8 1.25 x 25 mm SHCS titanium crank bolts with aluminum collars - model CR002 : stainless steel pedal washers

CHAIN:
Campagnolo Record - chrome nickel PTFE finish - hollow pins - drilled plates - 10s - 2004 model C-10 Ultra : Craig SuperLink III connector link

HUBSET:
American Classic - quick release hubs - small flange design - Black anodized aluminum alloy barrels and flanges - Campagnolo 9s/10s compatible - 2005 models Micro-58 32h front hub / RD-205 32h ultra-light rear hub (...with recall upgraded cam plate) : American Classic titanium QR skewers - long throw levers - 100 mm front / 130 mm rear

RIMS:
MAVIC CXP-33 - Black - Maxtal 6000 series alloy - SUP construction - UB control - 23.5 mm aero V-profile - 700c clincher - drilled for Presta valves - 32h front / 32h rear - 2005 model CXP-33 : Dynamis Disk removable rear wheel cover - carbon fiber construct - lenticular design - 700c - 2005 model : 3/8" Black nylon screw posts - model 06PSP038x

SPOKES:
Wheelsmith DB14 - Black - 14/15/14 gauge or 2.0/1.7/2.0 mm - double butted 304 stainless steel - model DB14-B : Wheelsmith Black finish brass nipples

TIRES:
Tufo CS-33 Special - 700c x 21 - 120 TPI casing - tubular clincher design - activated Silica tread compound - puncture proof ply - model CS-33 Special

CASSETTE:
Campagnolo Chorus - 12x25T (12-13-14-15-16-17-19-21-23-25) Ultra Drive - nickel chrome finish - alloy carriers - 10s - 2004 model CSK00-CH10 : Campagnolo Record 12T lockring - titanium - 2004 model CS-101T

FRONT DERAILLEUR:
Campagnolo Chorus CT Compact - Double - 10s - braze-on with separate 28.6 mm clamp-on adaptor - 2005 model FD5-CH2..CT : SRP titanium seat tube clamp bolt - M5 .8 x 14 mm TSHCS - model FD002 : SRP titanium cable clamp bolt - M5 .8 x 8 mm TSHCS - model FD001

REAR DERAILLEUR:
Campagnolo Chorus - Double - 10s short cage - 2003 model RD00-CH210 : SRP titanium cable clamp bolt - M5 .8 x 8 mm TSHCS - model FD001

SHIFT / BRAKE LEVERS:
Campagnolo Chorus - alloy ErgoPower levers - 10s x 2/3 - 2003 model EP03-CH10CG

BRAKE CALIPERS:
MAVIC SSC - dual pivot R3 concept - leaf springs / Permaglide bushings - 2004 model SSC : Kool-Stop Road Holder shoes with dual compound pads - model KS-RHC2 : SRP titanium recessed brake mount nuts - M6 1.0 x 25 mm (front) / M6 1.0 x 13 mm (rear) - models NUT004 35-25 (front) / NUT003 35-13 (rear) : SRP titanium brake cable clamp bolts - M5 .8 x 8 mm TSHCS (front & rear) - model FD001

PEDALS:
LOOK CX-6 - clipless - carbon fiber pedals with CrMo spindles - adjustable Q Factor / free arc / spring tension - Black - 2004 model CX-6

SADDLE:
Serfas Terazzo - Black leather cover - anatomical cut-out center channel - closed cell foam padding / perimeter gel insert - titanium matrix hollow tube rails - model TR-250

SEAT POST:
Velo Carbon - carbon fiber post - 7075-T6 alloy head - single bolt micro-adjust clamp - 300 mm x 27.2 mm - 2004 model : custom made 7075-T6 alloy safety sleeve : SRP titanium seat post bolt - M8 1.25 x 34 mm SHCS - model SP005

OTHER BITS:
Campagnolo seat post binder bolt - 8 mm diameter - 5 mm Allen key release - model 1072 : Campagnolo Record - ErgoPower blocks - aluminum - 2004 model EC-RE001 : SRP titanium DT cable stop bolts - M5 .8 x 8 mm BHCS - model 70-8 : Bianchi - BB derailleur cable guide : SRP BB cable guide bolt - M5 .8 x 5 mm BHCS - model 70-5 : Campagnolo ErgoPower cable set - 1.6 mm brake cables (800 mm front / 1600 mm rear) with housing (580 mm front / 1250 mm rear) - 1.2 mm shifter cables (1600 mm front / 2000 mm rear) with housing (680 mm front / 680 mm rear) - derailleur stay housing (330 mm) - cable ferrules - model CG-ER500 : Nashbar - brake cable crimps - 1.8 mm - alloy - model NS-CRO-B : Nashbar - derailleur cable crimps - 1.2 mm - alloy - model NS-CRO-D : Le Tour - cable donuts - 4 mm OD synthetic rubber - Black - model LT-CD-B

ACCESSORIES:
Raptor Components - water bottle cage - 74 mm carbon fiber - high gloss finish - model RC-200 : SRP titanium water bottle cage bolts - M5 .8 x 13 mm BHCS - model 70-13 : Tazi - 21 ounce (500 milliliter) Ergonomic water bottle - LDPE construction - wide mouth - Black - model TZ-WB-2323-B
Profile Design - seat post mounted dual bottle bracket - 6061-T6 alloy clamp - model Aqua Rack : Prime Line - water bottle cages - glass fiber body - 6061-T6 alloy clip - model PL-105 : EuroBottle - two 28 ounce (750 milliliter) water bottles - LDPE construction - wide mouth - Black - model WB-STD-750
Topeak - Aero Wedge saddle bag - Black - 1200 Denier Teflon coated nylon - 3M reflective strip - traditional straps with QR buckles - small size (40 c.i. capacity) - model TC2260B
Blackburn - frame pump - carbon fiber barrel - 6061-T6 alloy sleeve - anatomically shaped T-handle - thumb lock lever - model CF-L
Lizard Skins - chainstay guard - standard size - neoprene with Velcro attachment - cut to size - Black - model CHNDS100
Nashbar seat post minder - Black rubber - slip fit - model NA-SPM
